Seaflo Battery Selector Switch 2 Position

Switching system switch and power switch control

The Seaflo Battery Selector Switch 2 Position
allows the use of one battery for engine starting and one battery
for auxiliary. This heavy duty selector switch is rated at 300 Amps
momentary and 175 Amps continuous @ 12V. It disconnects the
battery/batteries safely to eliminate any power draw from the
battery when your vehicle or boat are not in use. Plus it can
isolate 1 battery or 2 batteries. Great for your boat, caravan,
4×4, showcar, trailer, winch power cable and more.

Seaflo Battery Selector Switch 2 Position
Features:

• Great for your boat, caravan, 4×4, showcar, trailer, winch
  power cable and more
• The selector switch will allow the use of one battery for
  engine starting and one battery for auxiliary
• Heavy Duty – rated at 300 Amps momentary, 175 Amps continuous @
  12V
• Can be used with 6V up to 32V systems to isolate and secure the
  electrical system
• Disconnects batteries safely, to eliminate any power draw from
  the battery when vehicle or boat are not in use
• Isolates 1 battery or 2 batteries
• Rotary dial has a spring-loaded keeper to lock the selected
  position
• UV stabilised black bakelite vapour-proof housing – Built to
  last in marine conditions
• Easy to install (wiring diagram included)
• Brass terminal studs and nuts and copper washers
• 4 mounting screw holes

Seaflo Battery Selector Switch 2 Position
Specifications:

• Volts: 50v
• Amp Draw: 275A
• Max Amp Draw: 1250A
• Switch position: 2
• Packing size (mm): 78*78*80
• N.W/G.W(kg): 0.20/0.30kg

Note:Does not include mounting screws
